Tp-Link Archer C6 AC1200 Wireless Mesh Gigabit Router
Specifications
WIRELESS | |
---|---|
STANDARDS | Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz |
WIFI SPEEDS | AC1200 5 GHz: 867 Mbps (802.11ac) 2.4 GHz: 400 Mbps (802.11n) |
WIFI RANGE | 3 Bedroom Houses 4× Fixed High-Performance Antennas Beamforming |
WIFI CAPACITY | Medium Dual-Band MU-MIMO Airtime Fairness |
WORKING MODES | Router Mode Access Point Mode |
SECURITY | |
---|---|
NETWORK SECURITY | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
GUEST NETWORK | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
WIFI ENCRYPTION | WPA WPA2 WPA3 |
HARDWARE | |
---|---|
PROCESSOR | 1.2 GHz CPU |
ETHERNET PORTS | 1× Gigabit WAN Port 4× Gigabit LAN Ports |
BUTTONS | WPS/Wi-Fi Button Power On/Off Button Reset Button |
POWER | 12 V ⎓ 1 A |
SOFTWARE | |
---|---|
PROTOCOLS | IPv4 IPv6 |
ONEMESH™ | OneMesh™ Supported Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products. |
PARENTAL CONTROLS | URL Filtering Time Controls |
WAN TYPES | Dynamic IP Static IP PPPoE PPTP L2TP |
QUALITY OF SERVICE | QoS by Device |
CLOUD SERVICE | OTA Firmware Upgrade TP-Link ID DDNS |
NAT FORWARDING | Port Forwarding Port Triggering DMZ UPnP |
IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN |
DHCP | Address Reservation DHCP Client List Server |
DDNS | TP-Link NO-IP DynDNS |
MANAGEMENT | Tether App Webpage |
OTHER | |
---|---|
SYSTEM REQUIREMENTS | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
CERTIFICATIONS | FCC, RoHS |
ENVIRONMENT | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
TEST DATA | |
---|---|
WIFI TRANSMISSION POWER | FCC: <30dBm(2.4GHz & 5GHz) |
WIFI RECEPTION SENSITIVITY | 5GHz: 11a 6Mbps:-93dBm;11a 54Mbps:-78dBm; 11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-65dBm; 11ac HT80 mcs9:-62dBm; 2.4GHz: 11g 54Mbps:-78dBm; 11n HT20 mcs7:-74dBm; 11n HT40 mcs7:-71dbm; |
PHYSICAL | |
---|---|
DIMENSIONS (W×D×H) | 8.5 × 4.6 × 1.2 in (215 × 117 × 32 mm) |
PACKAGE CONTENTS | Wi-Fi Router Archer C6 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
