Tp-Link Archer AX10 AX1500 Wi-Fi 6 Router
Specifications
SECURITY | |
---|---|
NETWORK SECURITY | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
GUEST NETWORK | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
VPN SERVER | OpenVPN PPTP |
WIFI ENCRYPTION | WPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x) |
WIRELESS | |
---|---|
STANDARDS | Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz |
WIFI SPEEDS | AX1500 5 GHz: 1201 Mbps (802.11ax) 2.4 GHz: 300 Mbps (802.11n) |
WIFI RANGE | 2-3 Bedroom Houses 4× Fixed High-Performance Antennas Beamforming |
WIFI CAPACITY | High Dual-Band OFDMA Airtime Fairness 4 Streams |
WORKING MODES | Router Mode Access Point Mode |
HARDWARE | |
---|---|
PROCESSOR | 1.5 GHz Triple-Core CPU |
ETHERNET PORTS | 1× Gigabit WAN Port 4× Gigabit LAN Ports |
BUTTONS | WPS/Wi-Fi Button Power On/Off Button Reset Button |
POWER | 12 V ⎓ 1 A |
SOFTWARE | |
---|---|
PROTOCOLS | IPv4 IPv6 |
EASYMESH | Mesh networking creates smooth, fast, stable roaming. Archer AX10 can flexibly build an EasyMesh network with EasyMesh-Compatible devices, which eliminates Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi. Seamless Wi-Fi connections with one network name, one-click setting and flexible scalability. |
PARENTAL CONTROLS | URL Filtering Time Controls |
WAN TYPES | Dynamic IP Static IP PPPoE PPTP L2TP |
QUALITY OF SERVICE | QoS by Device |
CLOUD SERVICE | Auto Firmware Upgrade OTA Firmware Upgrade TP-Link ID DDNS |
NAT FORWARDING | Port Forwarding Port Triggering DMZ UPnP |
IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN |
DHCP | Address Reservation DHCP Client List Server |
DDNS | TP-Link NO-IP DynDNS |
MANAGEMENT | Tether App Webpage |
OTHER | |
---|---|
SYSTEM REQUIREMENTS | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
CERTIFICATIONS | FCC, CE, RoHS |
ENVIRONMENT | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
TEST DATA | |
---|---|
WIFI TRANSMISSION POWER | CE: <20dBm(2.4 GHz) <23dBm(5.15 GHz~5.25 GHz) FCC: <30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) |
WIFI RECEPTION SENSITIVITY | 5 GHz: 11a 6Mbps:-97dBm 11a 54Mbps:-79dBm 11ac VHT20_MCS0:-96dBm 11ac VHT20_MCS11:-66dBm 11ac VHT40_MCS0:-94dBm 11ac VHT40_MCS11:-63dBm 11ac VHT80_MCS0:-91dBm 11ac VHT80_MCS11:-60dBm 11ax HE20_MCS0:-95dBm 11ax HE20_MCS11:-63dBm 11ax HE40_MCS0:-92dBm 11ax HE40_MCS11:-60dBm 11ax HE80_MCS0:-89dBm 11ax HE80_MCS11:-58dBm 2.4 GHz: 11g 6Mbps:-91dBm 11a 54Mbps:-74dBm 11n HT20_MCS0:-90dBm 11n HT20_MCS7:-73dBm 11n HT40_MCS0:-88dBm 11n HT40_MCS7:-70dBm |
PHYSICAL | |
---|---|
DIMENSIONS (W×D×H) | 10.2 × 5.3 ×1.5 in (260.2 × 135.0 × 38.6 mm) |
PACKAGE CONTENTS | Wi-Fi Router Archer AX10 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
