DJI RSC 2 Pro Combo

Watch video

3kg Max Payload

At an ultra-light 1.2 kg, DJI RSC 2 is one of the most lightweight professional-level camera gimbals available. With a max payload of 3 kg, users can mount a wide variety of camera setups and lenses.

Take Control with Your Phone

With ActiveTrack 3.0 built in, DJI RSC 2 uses the source signal from the camera to track your subject. RavenEye also utilizes Force Mobile to increase responsiveness and decrease latency.

Built-In OLED Screen

1-inch OLED screen can be used to control functions and parameters of the device and mounted camera.

Feel the Focus

The front dial offers precise focusing and single-handed operation in any scenario.

Specs

Peripheral

• Accessory Connections

• NATO port
  M4 Mounting Hole
  1/4”-20 Mounting Hole
  Cold Shoe Mount
  Video Transmission/ Follow Focus Motor Port (USB-C)
  RSS Camera Control Port (USB-C)
  Follow Focus Motor Port (USB-C)

• Battery

• Model: RB2-3400mAh -7.2 V
  Type: 18650 2S
  Capacity: 3400mAh
  Energy: 24.48 Wh
  Max Battery Life: 14 hours
  Charging time: Approx. 2 hours to fully charge with 18W fast charging (PD and QC 2.0 fast charging protocols are supported)
  Charging temperature: 5° to 40° C (41° to 104° F)

• Connections

• Bluetooth 5.0; USB-C

• Ronin App Requirements

• iOS 11 or above;
  Android 7.0 or above

Working Performance

• Load Weight (Reference Value)

• 3.0 kg (Handheld)

• Maximum Controlled Rotation Speed

• Pan axis: 360°/s
  Tilt axis: 360°/s
  Roll axis: 360°/s

• Mechanical Range

• Pan axis: 360° continuous rotation
  Roll axis: -240° to +95°
  Tilt axis: -112° to +214°

Mechanical & Electrical Characteristics

• Operating Frequency

• 2.4000-2.4835 GHz

• Transmission Power

• < 8 dBm

• Operating Temperature

• -20° to 45° C (-4° to 113° F)

• Weight

• Gimbal: Approx. 1216 g (including the battery and excluding Quick-Release Plate)
  Quick-Release Plate (Upper/Lower) Approx. 102 g
  Extended Grip/Tripod (Metal): Approx. 226 g
  Extended Grip/Tripod (Plastic): Approx. 160 g

• Gimbal Dimensions

• Folded: 260×210×75 mm (including the handle)
  Unfolded: 400×185×175 mm (including the handle and without the Extended Grip/Tripod)

Notes

• The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
